GYRE GENERATOR
Gyre 200 Series Advanced Controller
The new Gyre 200 Series Advanced
Controller is packed with features
Controller is packed with features
• Controls two Gyre pumps simultaneously.
• Comes with an OLED display (128x64 resolution).
• Built-in high-accuracy timer, user can setup different flow pattern during different time of the day.
• Support back-up battery (sold separately).
Water Movement Mode
Constant Speed Mode
Pulsing Mode
Gradual Pulsing Mode
Random Mode
Alternating Gyre Mode
Link-up Method
Synchronized
Anti-Synchronized
Timed Delay
Reversed Timed Delay
Break free from limitations!
With 5 water movement modes,4 ways to link up the pumps,2 preset cycles and a programmable 24 hours cycle - there is no more limitation on how you can set up the water circulation in your tank!
The all new "1-Controller-2-Pumps System"
Water Movement Mode Sample Diagram
Link-up Method Samples Illustrated
24-hours Cycle Illustrated
Preset 1-Lunar Tidal Cycle (LTC)
The Lunar Tidal Cycle (LTC) is a 24-hours cycle that mimics the kind of water current in the ocean during high and low tides.
Preset 2-Oceanic Gyre Cycle(OGC)
The Oceanic Gyre Cycle (OGC) is a 24-hours cycle that creates a gentle alternating gyre circulation within your aquarium.
INTRODUCING GYRE 200 SERIES
ADVANCED CONTROLLER
ADVANCED CONTROLLER
A pair of Gyre XF250 running Alternating Gyre Mode
in Anti-Synchronized method
in Anti-Synchronized method
Model Specification
| XF230 | XF250 | XF280 | |
| Power Consumption: | 8w-35w | 8w-60w | 10w-80w |
| Flow Rate: | 8000-9000 L/h (2100-2300 Gal/h) |
18000-20000 L/h (4800-5300 Gal/h) |
21000-22500 L/h (5550-6000 Gal/h) |
| Suitable for Aquarium: | 100-400L (25-100 Gal) | 200-3000L (50-800 Gal) | 750-3800L (200-1000 Gal) |
| Power Supply Unit: | 100-240V / 50-60Hz | 100-240V / 50-60Hz | 100-240V / 50-60Hz |
| Dimensions (L × W × H): | 255mm × 75mm × 40mm (10” × 2.95” × 1.57”) | 300mm × 73mm × 60mm (11.8” × 2.9” × 2.4”) | 378mm × 95mm × 52mm (14.8” × 3.8” × 2”) |
| Weight: | 650g(1.4 lb) | 850g(1.9 lb) | 1000g(2.2 lb) |
| Cable length: | |||
| Controller to pump | 2m(6.6’) | 2m(6.6’) | 2m(6.6’) |
| Power supply to controller | 1.5m(4.9’) | 1.5m(4.9’) | 1.5m(4.9’) |
| Glass thickness: | |||
| Standard Mount | 12mm(0.5”) | 18mm(0.7”) | 30mm(1.2”) |
| Reinforcement Mount | - - | 25mm(1”) | - - |
